Description
Features
- Vandal resistance, brass reinforced turret for increased side impact durability
- Memory Arc® returns the rotor to its original arc setting
- Non-strippable drive mechanism prevents damage from vandals
- Easy, wet/dry arc adjustment with slotted screwdriver through top of rotor from 50° to 330° part-circle, 360° non-reversing full-circle. Full and part circle operation in one unit
- SAM Seal-A-Matic™ check valve holds up to 10 feet (3.1 m) of elevation change
- 3-port, color-coded Rain Curtain nozzles for optimal long-range, midrange, and close-in watering
Specs
Throw Radius: 39 to 81 feet (11.9 to 24.7 m)
Precipitation rate: 12 to 31 mm/hr
Operating Pressure: 3.5 to 6.9 bar
Flow: 0.86 to 8.24 m3/h; 14.4 to 137.4 L/m
Inlet Diameter: 25mm BSP female threaded inlet
Nozzle outlet trajectory: 25º
Pop-up height: 5″ (12,7 cm)
5 year warranty
